DPAP provides effective bi-level positive airway pressure treatment for a variety of respiratory conditions including Obstructive Sleep Apnea (OSA).

A Bi-level device is ideal for the treatment of tubercular and non-tubercular lung diseases. There are significant numbers of Chronic Obstructive Pulmonary Disease (COPD) cases that require basic ventilation support. In such cases, Bi-level support without the complications of invasive ventilation proves to be very effective. Bi-level can also be effective in case of Acute Respiratory Distress Syndrome (ARDS) and asthma.

Product Features
  • Up to 7 Display Data
  • Built in up to 5 Safety Alarms
  • 4-20 or 4-25 or 4-30 cmH2O Selectable
  • Built in 5 Modes Setting – CPAP, S.T.S/T,PC
  • Low Noise Working <30dB
  • 2G Micro SD card
  • Pressure bar graph & Waveform data
  • Imported Germany blower
  • Non-invasive ventilator Clinic Analysis Software

download-catalog-2

DPAP Machines : Product specifications
Model ParametersDPAP20DPAP20PlusDPAP25PlusDPAP 30 Pro
ModeCPAP, SCPAP, S, S/T, TCPAP, S, S/T, TCPAP, S, S/T, T, PC
IPAP range4 – 20cmH2O4 – 20cmH2O4 – 25cmH2O4 – 30cmH2O
EPAP range4 – 20cmH2O4 – 20cmH2O4 – 20cmH2O4 – 20cmH2O
CPAP range4 – 20cmH2O4 – 20cmH2O4 – 20cmH2O4 – 20cmH2O
E-triggerAuto,1 to 3Auto,1 to 3Auto,1 to 6
Rise TimeAuto,1 to 3Auto,1 to 3Auto,1 to 6
IPAP Rise Time100-600 msec100-600 msec100-600 msec100-600 msec
Breath rate (BPM)Adjustable 0 – 40Adjustable 0 – 40Adjustable 0 – 40
Noise Level (dBA)Less than 30dB@ 10cmH2OLess than 30dB@ 10cmH2OLess than 30dB@ 10cmH2OLess than 30dBA 10cmH2O
CPAP Ramp
(minutes)
0 – 60minutes
1 minute increment
0 – 60minutes
1 minute increment
0 – 60minutes
1 minute increment
0 – 60minutes. 1 minute increment
Display DataIPAP, EPAP,
Vt, Vleak, BR
IPAP, EPAP,
Vt, Vleak
IPAP, EPAP
Vt, Vleak,
IPAP, EPAP, Vt, Vleak,
AlarmsPower failure
Mask Alarm
Power failure
Mask Alarm
Apnea Alarm
High/Low Rate Alarm
Power failure
Mask Alarm,
Apnea Alarm
High/Low Rate Alarm
Power failure, Mask off, Apnea, High / Low Rate, Motor failure, Low Minute Ventilation, Motor failure

Screens2.8″ TFT2.8″ TFT2.8″ TFT2.8″ TFT
DisplaysPressure bar graph/DataPressure bar graph/DataPressure bar graph/DataPressure bar graph, Data,
Waveform (Pressure, Flow Volume Curve)
Tube Length1.8m, 2m1.8m, 2m1.8m, 2m1.8m, 2m
Dimensions (L*W*H)21X21X11cm 21X21X11cm21X21X11cm21X21X11cm
Weight (kg)2.1 2.12.12.1
Heated HumidifierOptionalOptionalOptionalOptional
MemoryMicro SD CardMicro SD CardMicro SD CardMicro SD Card
Warranty2 Years2 Years2 Years2 Years
