CPAP Machine – ECOSTAR Auto
EcoStarTM Auto is a Positive Pressure device with a large range of features to improve the comfort and treatment compliance of patients suffering from Obstructive Sleep Apnea Syndrome (OSAS). Adapts easily to the user’s daily routine, and guarantees high-performance, comfort and ease of use. The air inlet filter is highly accessible, making it easy for the user to independently perform routine maintenance on the device.
The EcoStarTM Auto algorithm responds to moderate obstructive events such as inspiratory flow limitation and snoring. The differentiation between obstructive and central events allows the device to deliver the optimum pressure at anytime, only increasing the pressure in case of apneas or hypopneas identified as obstructive by the algorithm.
Product Features
- Disconnected mask function
- Specific auto-calibration function.
- Auto ON function
- Ramp Function.
- Calibration Comfort Function
- Data Management and sleep apnea analysis software
| Mode | CPAP, Auto CPAP |
| Pressures delivered | 4-20 cm H20 (± 0.5 cm H2O), adjustable in steps of 0.5 cm H2O |
| Max. flow rate for a pressure drop of 1 cm H2O at patient inlet | 150 I/min at 20 cm H2O without humidifier |
| Ramp time | 0-45 minutes, adjustable in 5 minutes steps |
| Noise level | 27.5 dBA measured with a tolerance of 3 dBA according to NF EN ISO 17510-1:2009 |
| Size | Width 14 cm x Length 20 cm x Height 8 cm |
| Weight | 0.750 kg without power supply |
| Electrical supply | Input range 100-240V (50-60 Hz) |
| Maximum electrical power | 25 W (without humidifier) |
| 93 / 42 / EC Classification | Class II A |
| Temperature | +5 °C to +40 °C, +5 °C to +35 °C with humidifier |
| Humidity | 10 – 95% relative humidity without condensation |
| Storage | –20 °C to +60 °C, ± 95% relative humidity without condensation |
| Warranty | Three years |
| Altitude | From sea level to 2400 metres |
