Oxygen Unlimited
The newest member in Nidek Medical’s family of Oxygen Concentrators, the Nuvo Lite, is by far the most innovative evolution in our pursuit to provide the absolute best to our customers. We’ve revolutionized the Nuvo by making it lighter and more compact, but with more functionality and benefits. Weighing only 13.6 Kgs, it is among the lightest in the industry. The Nuvo Lite is FDA approved and guarantees complete satisfaction and convenience.
Available Models : Nuvo Lite | Nuvo Standard | Nuvo 8 | Nuvo 10
Nuvo Lite
Product Features
- Lite’ – Only 13.6 Kgs
- Quiet – Ultra quiet operation, sound level <40 dBA
- Compact – 360 x 220 x 580 mm
- Accurate – Lockable flow control valve, range from 0.125 – 5 LPM
- Economical – Very low power consumption, only 290 W
- Superior design – Direct access to air inlet filer, electronic hour meter and alarm battery
- Reaches full purity in less than 3 minutes
- High efficiency compressor
- Easy usage and maintenance
- Operating system – Timed cycle / Rapid Pressure Swing
- Self monitoring alarm system (in OMS model)
| Size: | 360 x 220 x 580 mm |
| Weight : | 13.6 Kgs |
| Continuous flow settings: | 0.125 – 5 LPM |
| Oxygen Concentration: | 90% (+6.5% / -3%) at 5 LPM |
| Oxygen output pressure: | 7 PSI |
| Sound level: | Less Than 40 dBA |
| Power specification: | 230 V, 50 Hz |
| Power Consumption | 290 W |
| Filters: | Cabinet, Compressor Intake and Bacteria |
Nuvo Standard
Product Features
- Quiet Operation – Sound Level less than 47 dBA
- Lightweight – 22.7 Kgs – Easy to move
- Slender & Sleek design with integrated handle
- Easy access to filters & battery
- Superior grade of molecular sieve
- Patented maintenance free rotary poppet valve
- Exclusive moisture reducing wick assembly
- Reinforced base with recessed casters to guard against breakage
- Spring mounted high efficiency Thomas compressor
- Patented RPSA (Rapid Pressure Swing Absorption)
- Simple design for ease of use & maintenance
| Size (L x W x H) : | 394mm x 396mm x 706mm |
| Weight : | 22.7 Kgs |
| Safety Alarms : | Power Failure, Process Failure High & Low Pressure |
| Oxygen Purity : | 90% (+5%/-3%) |
| Oxygen Output : | 0 to 5 LPM |
| Sound level: | Less Than 47 dBA |
| Outlet Pressure : | 7 psi |
| Power Consumption | 420 Watts average |
| Filters: | Cabinet, Compressor Intake and Bacteria |
| Warranty: | One Year |
Nuvo 8
Product Features
The strongest member of the Nuvo family, the Nuvo 8 provides large flow rates at high pressures, giving you expanded opportunities to provide for your patients. The machine is FDA, CE and ISO certified
| Size (L x W x H) : | 39.4mm x 39.6mm x 70.6mm |
| Weight : | 25.2 Kgs |
| Oxygen Purity : | 90% (+5% /-3%) |
| Sound level: | 47 dBA |
| Outlet Pressure : | 15 psi |
| Power Consumption | 500 Watts |
| Safety Alarms | Power Failure, Process Failure, High & Low Pressure |
| Warranty: | One Year |
Nuvo 10
Product Features
The strongest member of the Nuvo family, the Nuvo 10 provides large flow rates at high pressures, giving you expanded opportunities to provide for your patients. The machine is FDA, CE and ISO certified
| Size (L x W x H) : | 39.4mm x 39.6mm x 70.6mm |
| Weight : | 29.26 Kgs |
| Oxygen Purity : | 90% (+ 5% /- 3%) |
| Sound level: | 47 dBA |
| Outlet Pressure : | 15 psi |
| Power Consumption | 600 Watts average |
| Warranty: | One Year |
